2016 HARTFORD SW-216 DOUBLE COLUMN MACHINING CENTER

Table Size 2,000 x 1,450 MM Table Load 7,000 KGS X Y Z Travels 2,100 / 1,600 / 780 Z 1,070 MM Width Between Columns 1,600 MM Spindle Nose To Table 220 ~ 1,000 230 ~ 1,300 MM Spindle Taper #50 BBT CAT DIN Spindle Speeds 6,000 RPM Spindle Power 18.5 22.0 26.0 KW Rapid Traverse Rates 12 / 12 / 15 M/MIN Number of ATC Stations 32 Tool
